Lian Li VG4v4 4-Slot Vertical GPU Kit with PCIe 5.0 Riser – Black
₨ 22,000
- Included riser: 200mm PCIe 5.0 x16.
- Supported card thickness: Up to four slots, with case/layout checks.
- Revision: VG4v4; do not substitute older VG4-4 specifications.
- Bracket dimensions (L × W × H): 168.63 × 147.5 × 234.86 mm.
Lian Li · 4 Slots Vertical GPU Kit VG4v4
Three mounting heights and three GPU display angles
The VG4v4 is Lian Li’s four-slot vertical GPU kit with a 200mm PCIe 5.0 x16 riser. It offers forward, neutral and backward mounting angles, three height settings, a support arm and integrated 5V ARGB lighting. Selected finish: Black.
Plan the slot opening and forward shift
Lian Li specifies the case opening/layout for vertical and angled mounting, and notes a 31mm forward shift after installation. Check case depth, bottom fans or radiator clearance, card dimensions and power-cable routing. A four-slot thickness limit does not guarantee every four-slot card fits every case.
Set the height before fixing the support
The three mounting heights are spaced 10.16mm apart. Higher positions can provide space for bottom cooling; the lowest can leave an AIO display more visible. After adjustment, secure the height screw. Set the anti-sag arm for the chosen GPU height and tilt.
Check motherboard support-arm clearance
ATX and Micro-ATX share a support-arm configuration; E-ATX uses an extension arm. Some E-ATX side accessories can interfere. Lian Li also excludes specific PCIe-slot positions for the anti-sag bracket, so follow the exact manual rather than assuming a universal mounting location.
Install the riser with the system powered off
Fully seat the riser at both the motherboard and GPU while power is off. Lian Li recommends an up-to-date motherboard BIOS for PCIe 5.0 use. Use the case’s PCIe bracket screws and the appropriate GPU securing screws described by the official installation instructions.
4 Slots Vertical GPU Kit VG4v4 specifications
- Revision
- VG4v4; do not substitute older VG4-4 specifications
- Bracket dimensions (L × W × H)
- 168.63 × 147.5 × 234.86 mm
- Material
- Steel
- Supported card thickness
- Up to four slots, with case/layout checks
- Included riser
- 200mm PCIe 5.0 x16
- Lighting
- 5V ARGB motherboard synchronization
- Height adjustment
- Three levels, in 10.16mm increments
- Mounting angles
- Forward / neutral / backward
- GPU position change
- Moves the GPU forward by 31mm
- Colour
- Black
4 Slots Vertical GPU Kit VG4v4 build questions
Is this only a bracket without a riser cable?
No. This VG4v4 kit includes the 200mm PCIe 5.0 riser. It is a different item from the O11D EVO upright bracket-only listings.
Is O11D MINI V2 an unrestricted fit?
No. Lian Li lists limited use in O11D MINI V2 and recommends that case’s included vertical kit for the preferred installation.
Can I install it in another brand of case?
Only if that chassis meets the official opening, mounting and internal-clearance requirements. Check the exact installation diagram; brand or ATX form factor alone is not proof of fit.
Official Lian Li 4 Slots Vertical GPU Kit VG4v4 product information and manuals
Specifications and box contents may vary by region or manufacturer revision. Please check the linked manufacturer information and confirm any essential feature or included accessory with GameOn.pk before ordering.
| Brand | Lian Li |
|---|---|
| Color | Black |
